Find the margin width necessary to fit text or a legend next to a plot

Calculates the margin width necessary to fit text or a legend next to a plot.

getMarginWidth(side=4,labels,is.legend=FALSE)

Arguments

side

Which side of the plot (as in axis).

labels

The text to place next to the plot.

is.legend

Whether the text is in a legend or not.

Details

getMarginWidth reads parameters about the current plot and calculates the left or right (default) margin necessary to fit the strings passed as labels or a legend containing those strings.

Value

A two element list containing the number of margin lines necessary to fit the text or legend and the horizontal center of the margin in user units.

Author

Jim Lemon

Examples

 plot(rnorm(10))

 newmarinfo<-getMarginWidth(labels=c("Long label","Even longer label"))
#> plotprop 0.8228571 marprop 0.06 plotwidth 9.72 marwidth 2.382497
 oldmar<-par("mar")
 par(mar=c(oldmar[1:3],newmarinfo$newmar))
 plot(rnorm(10))
 par(xpd=TRUE)
 text(rep(newmarinfo$marcenter,2),c(0.5,-0.5),
  c("Long label","Even longer label"))

 par(mar=oldmar,xpd=FALSE)
