Plot a legend for a visual predictive check (VPC)

Source: R/plot_vpclegend.R

Plot a legend for a visual predictive check (VPC)

plot_vpclegend(
  ci = c(0.05, 0.95),
  pi = c(0.05, 0.95),
  shown = NULL,
  lloq = NULL,
  update = NULL,
  ...
)

Arguments

ci

simulated confidence interval plotted. Should match argument passed to vpc::vpc(). Default is c(0.05, 0.95).

pi

prediction intervals plotted. Should match argument passed to vpc::vpc(). Default is c(0.05, 0.95).

shown

Named list of logicals specifying which layers to include on the plot. Passed to show argument of vpc::vpc().

Defaults are:

  • Observed points: obs_dv = TRUE.

  • Observed quantiles: obs_ci = TRUE

  • Simulated inter-quantile range:pi = FALSE

  • Simulated inter-quantile area: pi_as_area = FALSE

  • Simulated Quantile CI: pi_ci = TRUE

  • Observed Median: obs_median = TRUE

  • Simulated Median: sim_median = FALSE

  • Simulated Median CI: sim_median_ci = TRUE

lloq

label for lower limit of quantification in the plot legend.

update

list containing the plot elements to be updated. Default is set by pmxhelpr_vpc_theme().

...

Other arguments passed to ggplot2::theme().

Value

a ggplot2 object

Examples

plot_vpclegend()

plot_vpclegend(
pi = c(0.025, 0.975),
ci = c(0.025, 0.925),
 shown = list(obs_dv = FALSE, obs_ci = TRUE,
 pi = FALSE, pi_as_area = FALSE, pi_ci = TRUE,
 obs_median = TRUE,
 sim_median =FALSE, sim_median_ci = TRUE))
