Continuous scale

cscale(x, palette, na.value = NA_real_, trans = transform_identity())

Arguments

x

vector of continuous values to scale

palette

palette to use.

Built in palettes: pal_area, pal_brewer, pal_dichromat, pal_div_gradient, pal_gradient_n, pal_grey, pal_hue, pal_identity, pal_linetype, pal_manual, pal_rescale, pal_seq_gradient, pal_shape, pal_viridis

na.value

value to use for missing values

trans

transformation object describing the how to transform the raw data prior to scaling. Defaults to the identity transformation which leaves the data unchanged.

Built in transformations: transform_asinh, transform_asn, transform_atanh, transform_boxcox, transform_compose, transform_date, transform_exp, transform_hms, transform_identity, transform_log, transform_log10, transform_log1p, transform_log2, transform_logit, transform_modulus, transform_probability, transform_probit, transform_pseudo_log, transform_reciprocal, transform_reverse, transform_sqrt, transform_time, transform_timespan, transform_yj .

Examples

with(mtcars, plot(disp, mpg, cex = cscale(hp, pal_rescale())))

with(mtcars, plot(disp, mpg, cex = cscale(hp, pal_rescale(),
  trans = transform_sqrt()
)))

with(mtcars, plot(disp, mpg, cex = cscale(hp, pal_area())))

with(mtcars, plot(disp, mpg,
  pch = 20, cex = 5,
  col = cscale(hp, pal_seq_gradient("grey80", "black"))
))
