Getting Started with np

Source: vignettes/np_getting_started.Rmd
np_getting_started.Rmd

This vignette is meant to be the smallest useful package-side introduction to np. The emphasis is on one clean workflow that users can run after installation: choose a bandwidth, fit a model, inspect the result, and plot it.

Broader worked examples, package comparisons, and method-specific articles are better carried by the gallery site:

The basic workflow

In np, the bandwidth object is often the key object in the analysis.

  1. compute or inspect a bandwidth object,
  2. fit the model,
  3. summarize or plot the result.

A simple regression example

library(np)
#> np 0.80-1
#> Examples and guides at https://jeffreyracine.github.io/gallery/
#> See also vignette("np_getting_started", package = "np")
data(cps71, package = "np")

bw <- npregbw(logwage ~ age, data = cps71)
summary(bw)
#>
#> Regression Data (205 observations, 1 variable(s)):
#>
#> Regression Type: Local-Constant
#> Bandwidth Selection Method: Least Squares Cross-Validation
#> Formula: logwage ~ age
#> Bandwidth Type: Fixed
#> Objective Function Value: 0.316055 (achieved on multistart 1)
#> Number of Function Evaluations: 47
#> Evaluation cache (Powell): 17 hits / 41 lookups (41.5%)
#>
#> Exp. Var. Name: age Bandwidth: 1.892158  Scale Factor: 0.4487743
#>
#> Continuous Kernel Type: Second-Order Gaussian
#> No. Continuous Explanatory Vars.: 1
#> Estimation Time: 0.278 seconds

fit <- npreg(bws = bw)
summary(fit)
#>
#> Regression Data: 205 training points, in 1 variable(s)
#>                    age
#> Bandwidth(s): 1.892158
#>
#> Kernel Regression Estimator: Local-Constant
#> Bandwidth Type: Fixed
#> Residual standard error: 0.5307943
#> R-squared: 0.3108675
#>
#> Continuous Kernel Type: Second-Order Gaussian
#> No. Continuous Explanatory Vars.: 1
#> Estimation Time: 0.282 seconds (optim 0.278s, fit 0.004s)

Plotting the fitted relationship

plot(cps71$age, cps71$logwage, cex = 0.25, col = "grey")
lines(cps71$age, fitted(fit), col = 2, lwd = 2)

Use the retained bandwidth object when only the evaluation points or requested outputs change. Keep the original training data available to the fitted call.

new_points <- data.frame(age = c(25, 40, 55))
predict(fit, newdata = new_points)
#> [1] 13.20439 13.67951 13.72584

# This refits at the existing bandwidth; it does not run bandwidth selection.
fit_inference <- npreg(bws = fit$bws, gradients = TRUE, se = TRUE)
head(se(fit_inference))
#> [1] 0.1516384 0.1188048 0.1188048 0.1188048 0.1188048 0.1188048
head(gradients(fit_inference))
#>           [,1]
#> [1,] 0.1234769
#> [2,] 0.1320906
#> [3,] 0.1320906
#> [4,] 0.1320906
#> [5,] 0.1320906
#> [6,] 0.1320906
head(gradients(fit_inference, se = TRUE))
#>            [,1]
#> [1,] 0.05264137
#> [2,] 0.04164114
#> [3,] 0.04164114
#> [4,] 0.04164114
#> [5,] 0.04164114
#> [6,] 0.04164114

prediction <- predict(fit, newdata = new_points, se.fit = TRUE)
prediction$fit
#> [1] 13.20439 13.67951 13.72584
prediction$se.fit
#> [1] 0.06316922 0.08472946 0.11814011

The switches and extractors have different roles:

Request Purpose
se = TRUE in an estimator call Compute its supported fit-time uncertainty.
gradients = TRUE in an estimator call Compute supported derivatives or categorical contrasts. Add se = TRUE for their standard errors.
se(fit) or gradients(fit, se = TRUE) Read stored standard errors; do not refit or repeat search.
predict(fit, newdata = ..., se.fit = TRUE) Evaluate predictions and their supported standard errors.
vcov(fit) Read coefficient covariance for families such as npindex and npplreg, not a universal covariance of the fitted surface.
plot(fit, errors = "bootstrap") or errors = "asymptotic" Request plot-time uncertainty through that family’s plot method.

Consult the estimator’s help for supported kernels, bandwidth types and derivative orders. Uncertainty not requested at fitting produces an extractor error with a no-search refit hint. This differs from an unsupported inference configuration or an undefined evaluation row (for example, no compact-kernel support). Inspect warnings and NA results rather than treating them as zero uncertainty. Asymptotic results condition on the selected smoothing settings; they do not include bandwidth or polynomial-degree selection uncertainty. Supported plot targets provide asymptotic simultaneous variability bands over the finite evaluation grid within each panel, conditional on the selected smoothing settings. They do not provide joint coverage across separate panels. See ?np.plot for supported targets, working-covariance assumptions and unavailability conditions.

Moving from 0.70-5 to 0.80-1

Fit-time standard errors are now opt-in (se = TRUE) across the principal families. The intentional exception is npindex, whose default se = TRUE, se.type = "asymptotic" includes coefficient covariance; se = FALSE requests a point-only fit. Gradients remain a separate request.

Use current dotted argument names such as gradient.order, data.overlay and data.rug, and B for bootstrap replication counts where documented. Unknown named arguments are rejected with a spelling hint where available; an old misspelling that was previously ignored can therefore surface now. The full package NEWS (news(package = "np")) lists the replacements and family-specific changes. The Gallery FAQ provides further troubleshooting guidance. Refit using fit$bws as above when the missing piece is uncertainty or gradients, not a new bandwidth choice.

Mixed data

One important feature of np is that it handles mixed data directly. Variable class matters: unordered categorical variables should be factors, and ordered categorical variables should be ordered factors when appropriate.

set.seed(42)
mydat <- data.frame(
  y = rnorm(200),
  x_cont = runif(200),
  x_unordered = factor(sample(c("a", "b", "c"), 200, replace = TRUE)),
  x_ordered = ordered(sample(1:4, 200, replace = TRUE))
)

bw_mixed <- npregbw(y ~ x_cont + x_unordered + x_ordered, data = mydat)
fit_mixed <- npreg(bws = bw_mixed)
summary(fit_mixed)
#>
#> Regression Data: 200 training points, in 3 variable(s)
#> Search Parameter(s):
#>          x_cont  x_unordered  x_ordered
#> Type  Bandwidth       Lambda     Lambda
#> Value   1868520    0.6610048  0.9981613
#> Max          --    0.6666667          1
#>
#> Kernel Regression Estimator: Local-Constant
#> Bandwidth Type: Fixed
#> Residual standard error: 0.9721457
#> R-squared: 0
#>
#> Continuous Kernel Type: Second-Order Gaussian
#> No. Continuous Explanatory Vars.: 1
#>
#> Unordered Categorical Kernel Type: Aitchison and Aitken
#> No. Unordered Categorical Explanatory Vars.: 1
#>
#> Ordered Categorical Kernel Type: Li and Racine
#> No. Ordered Categorical Explanatory Vars.: 1
#> Estimation Time: 0.552 seconds (optim 0.549s, fit 0.003s)

For local-polynomial-capable methods, np now supports joint selection of polynomial order and bandwidth. The modern route is to use search.engine = "nomad+powell" when you want the search to choose both together.

If you want the recommended route without spelling out all of the LP tuning arguments, use nomad = TRUE. This is a documented convenience preset, not a generic optimizer alias: it fills only missing values among the LP degree-search controls and leaves compatible explicit overrides in place. This route uses the NOMAD backend supplied by the required crs dependency (version 0.15-46 or later), installed with np.

if (requireNamespace("crs", quietly = TRUE) &&
    utils::packageVersion("crs") >= package_version("0.15-46")) {
  set.seed(7)
  n <- 120
  x <- runif(n, -1, 1)
  y <- x + 0.4 * x^2 + rnorm(n, sd = 0.18)

  fit_nomad <- npreg(y ~ x, nomad = TRUE, degree.max = 1L, nmulti = 1L)
  fit_nomad$bws$nomad.shortcut

  # Tune one component explicitly while leaving the rest of the preset in place.
  fit_nomad_direct <- npreg(
    y ~ x,
    nomad = TRUE,
    search.engine = "nomad",
    degree.max = 1L,
    nmulti = 1L
  )
}

The same convenience entry point is available for the other LP-capable families: npcdens, npcdist, npplreg, npscoef, and npindex, together with their corresponding *bw constructors.

Keep the first run modest and runnable. Fuller worked examples belong on the gallery rather than in this package vignette.

Data preparation matters

In np, the formula interface tells the function which variables are the response and regressors. It is not imposing an ordinary linear-additive model.

It is also important not to pass blocks of 0/1 dummies as if this were a standard linear-model workflow. If the underlying variable is categorical, it is usually better to keep it as one factor or ordered variable.

Other common starting points

This vignette keeps the package-side introduction intentionally narrow. Other common first routes are:

Those broader branches are better carried by help pages and website articles than by a single shipped vignette.

Where to go next
