Plot Effects of Variables Estimated by a Regression Model Fit

Uses lattice graphics to plot the effect of one or two predictors on the linear predictor or X beta scale, or on some transformation of that scale. The first argument specifies the result of the Predict function. The predictor is always plotted in its original coding. plot.Predict uses the xYplot function unless formula is omitted and the x-axis variable is a factor, in which case it reverses the x- and y-axes and uses the Dotplot function.

If data is given, a rug plot is drawn showing the location/density of data values for the $x$-axis variable. If there is a groups (superposition) variable that generated separate curves, the data density specific to each class of points is shown. This assumes that the second variable was a factor variable. The rug plots are drawn by scat1d. When the same predictor is used on all $x$-axes, and multiple panels are drawn, you can use subdata to specify an expression to subset according to other criteria in addition.

To plot effects instead of estimates (e.g., treatment differences as a function of interacting factors) see contrast.rms and summary.rms.

pantext creates a lattice panel function for including text such as that produced by print.anova.rms inside a panel or in a base graphic.

# S3 method for class 'Predict'
plot(x, formula, groups=NULL,
     cond=NULL, varypred=FALSE, subset,
     xlim, ylim, xlab, ylab,
     data=NULL, subdata, anova=NULL, pval=FALSE, cex.anova=.85,
     col.fill=gray(seq(.825, .55, length=5)),
     adj.subtitle, cex.adj, cex.axis, perim=NULL, digits=4, nlevels=3,
     nlines=FALSE, addpanel, scat1d.opts=list(frac=0.025, lwd=0.3),
     type=NULL, yscale=NULL, scaletrans=function(z) z, ...)

pantext(object, x, y, cex=.5, adj=0, fontfamily="Courier", lattice=TRUE)

Arguments

x: a data frame created by Predict, or for pantext the x-coordinate for text
formula: the right hand side of a lattice formula reference variables in data frame x. You may not specify formula if you varied multiple predictors separately when calling Predict. Otherwise, when formula is not given, plot.Predict constructs one from information in x.
groups: an optional name of one of the variables in x that is to be used as a grouping (superpositioning) variable. Note that groups does not contain the groups data as is customary in lattice; it is only a single character string specifying the name of the grouping variable.
cond: when plotting effects of different predictors, cond is a character string that specifies a single variable name in x that can be used to form panels. Only applies if using rbind to combine several Predict results.
varypred: set to TRUE if x is the result of passing multiple Predict results, that represent different predictors, to rbind.Predict. This will cause the .set. variable created by rbind to be copied to the .predictor. variable.
subset: a subsetting expression for restricting the rows of x that are used in plotting. For example, predictions may have been requested for males and females but one wants to plot only females.
xlim: This parameter is seldom used, as limits are usually controlled with Predict. One reason to use xlim is to plot a factor variable on the x-axis that was created with the cut2 function with the levels.mean option, with val.lev=TRUE specified to plot.Predict. In this case you may want the axis to have the range of the original variable values given to cut2 rather than the range of the means within quantile groups.
ylim: Range for plotting on response variable axis. Computed by default.
xlab: Label for x-axis. Default is one given to asis, rcs, etc., which may have been the "label" attribute of the variable.
ylab: Label for y-axis. If fun is not given, default is "log Odds" for lrm, "log Relative Hazard" for cph, name of the response variable for ols, TRUE or log(TRUE) for psm, or "X * Beta" otherwise.
data: a data frame containing the original raw data on which the regression model were based, or at least containing the $x$-axis and grouping variable. If data is present and contains the needed variables, the original data are added to the graph in the form of a rug plot using scat1d.
subdata: if data is specified, an expression to be evaluated in the data environment that evaluates to a logical vector specifying which observations in data to keep. This will be intersected with the criterion for the groups variable. Example: if conditioning on two paneling variables using |a*b you can specify subdata=b==levels(b)[which.packet()[2]], where the 2 comes from the fact that b was listed second after the vertical bar (this assumes b is a factor in data. Another example: subdata=sex==c('male','female')[current.row()].
anova: an object returned by anova.rms. If anova is specified, the overall test of association for predictor plotted is added as text to each panel, located at the spot at which the panel is most empty unless there is significant empty space at the top or bottom of the panel; these areas are given preference.
pval: specify pval=TRUE for anova to include not only the test statistic but also the P-value
cex.anova: character size for the test statistic printed on the panel
col.fill: a vector of colors used to fill confidence bands for successive superposed groups. Default is inceasingly dark gray scale.
adj.subtitle: Set to FALSE to suppress subtitling the graph with the list of settings of non-graphed adjustment values.
cex.adj: cex parameter for size of adjustment settings in subtitles. Default is 0.75 times par("cex").
cex.axis: cex parameter for x-axis tick labels
perim: perim specifies a function having two arguments. The first is the vector of values of the first variable that is about to be plotted on the x-axis. The second argument is the single value of the variable representing different curves, for the current curve being plotted. The function's returned value must be a logical vector whose length is the same as that of the first argument, with values TRUE if the corresponding point should be plotted for the current curve, FALSE otherwise. See one of the latter examples. If a predictor is not specified to plot, NULL is passed as the second argument to perim, although it makes little sense to use perim when the same perim is used for multiple predictors.
digits: Controls how numeric variables used for panel labels are formatted. The default is 4 significant digits.
nlevels: when groups and formula are not specified, if any panel variable has nlevels or fewer values, that variable is converted to a groups (superpositioning) variable. Set nlevels=0 to prevent this behavior. For other situations, a numeric x-axis variable with nlevels or fewer unique values will cause a dot plot to be drawn instead of an x-y plot.
nlines: If formula is given, you can set nlines to TRUE to convert the x-axis variable to a factor and then to an integer. Points are plotted at integer values on the x-axis but labeled with category levels. Points are connected by lines.
addpanel: an additional panel function to call along with panel functions used for xYplot and Dotplot displays
scat1d.opts: a list containing named elements that specifies parameters to scat1d when data is given. The col parameter is usually derived from other plotting information and not specified by the user.
type: a value ("l","p","b") to override default choices related to showing or connecting points. Especially useful for discrete x coordinate variables.
yscale: a lattice scale list for the y-axis to be added to what is automatically generated for the x-axis. Example: yscale=list(at=c(.005,.01,.05),labels=format(c(.005,.01,.05))). See xyplot
scaletrans: a function that operates on the scale object created by plot.Predict to produce a modified scale object that is passed to the lattice graphics function. This is useful for adding other scales options or for changing the x-axis limits for one predictor.
...: extra arguments to pass to xYplot or Dotplot. Some useful ones are label.curves and abline. Set label.curves to FALSE to suppress labeling of separate curves. Default is TRUE, which causes labcurve to be invoked to place labels at positions where the curves are most separated, labeling each curve with the full curve label. Set label.curves to a list to specify options to labcurve, e.g., label.curves= list(method="arrow", cex=.8). These option names may be abbreviated in the usual way arguments are abbreviated. Use for example label.curves=list(keys=letters[1:5]) to draw single lower case letters on 5 curves where they are most separated, and automatically position a legend in the most empty part of the plot. The col, lty, and lwd parameters are passed automatically to labcurve although they may be overridden here. It is also useful to use ... to pass lattice graphics parameters, e.g. par.settings=list(axis.text=list(cex=1.2), par.ylab.text=list(col='blue',cex=.9),par.xlab.text=list(cex=1)).
object: an object having a print method
y: y-coordinate for placing text in a lattice panel or on a base graphics plot
cex: character expansion size for pantext
adj: text justification. Default is left justified.
fontfamily: font family for pantext. Default is "Courier" which will line up columns of a table.
lattice: set to FALSE to use text instead of ltext in the function generated by pantext, to use base graphics

Value

a lattice object ready to print for rendering.

Details

When a groups (superpositioning) variable was used, you can issue the command Key(...) after printing the result of plot.Predict, to draw a key for the groups.

Author

Frank Harrell
Department of Biostatistics, Vanderbilt University
fh@fharrell.com

References

Fox J, Hong J (2009): Effect displays in R for multinomial and proportional-odds logit models: Extensions to the effects package. J Stat Software 32 No. 1.

Note

If plotting the effects of all predictors you can reorder the panels using for example p <- Predict(fit); p$.predictor. <- factor(p$.predictor., v) where v is a vector of predictor names specified in the desired order.

Examples

n <- 1000    # define sample size
set.seed(17) # so can reproduce the results
age            <- rnorm(n, 50, 10)
blood.pressure <- rnorm(n, 120, 15)
cholesterol    <- rnorm(n, 200, 25)
sex            <- factor(sample(c('female','male'), n,TRUE))
label(age)            <- 'Age'      # label is in Hmisc
label(cholesterol)    <- 'Total Cholesterol'
label(blood.pressure) <- 'Systolic Blood Pressure'
label(sex)            <- 'Sex'
units(cholesterol)    <- 'mg/dl'   # uses units.default in Hmisc
units(blood.pressure) <- 'mmHg'

# Specify population model for log odds that Y=1
L <- .4*(sex=='male') + .045*(age-50) +
  (log(cholesterol - 10)-5.2)*(-2*(sex=='female') + 2*(sex=='male'))
# Simulate binary y to have Prob(y=1) = 1/[1+exp(-L)]
y <- ifelse(runif(n) < plogis(L), 1, 0)

ddist <- datadist(age, blood.pressure, cholesterol, sex)
options(datadist='ddist')

fit <- lrm(y ~ blood.pressure + sex * (age + rcs(cholesterol,4)),
               x=TRUE, y=TRUE)
#> Error in Design(data, formula = formula): dataset ddist not found for options(datadist=)
an <- anova(fit)
#> Error: object 'fit' not found
# Plot effects of all 4 predictors with test statistics from anova, and P
plot(Predict(fit), anova=an, pval=TRUE)
#> Error: object 'fit' not found
plot(Predict(fit), data=llist(blood.pressure,age))
#> Error: object 'fit' not found
                         # rug plot for two of the predictors

p <- Predict(fit, name=c('age','cholesterol'))   # Make 2 plots
#> Error: object 'fit' not found
plot(p)
#> Error: object 'p' not found

p <- Predict(fit, age=seq(20,80,length=100), sex, conf.int=FALSE)
#> Error: object 'fit' not found
                         # Plot relationship between age and log
                         # odds, separate curve for each sex,
plot(p, subset=sex=='female' | age > 30)
#> Error: object 'p' not found
# No confidence interval, suppress estimates for males <= 30

p <- Predict(fit, age, sex)
#> Error: object 'fit' not found
plot(p, label.curves=FALSE, data=llist(age,sex))
#> Error: object 'p' not found
                         # use label.curves=list(keys=c('a','b'))'
                         # to use 1-letter abbreviations
                         # data= allows rug plots (1-dimensional scatterplots)
                         # on each sex's curve, with sex-
                         # specific density of age
                         # If data were in data frame could have used that
p <- Predict(fit, age=seq(20,80,length=100), sex='male', fun=plogis)
#> Error: object 'fit' not found
                         # works if datadist not used
plot(p, ylab=expression(hat(P)))
#> Error: object 'p' not found
                         # plot predicted probability in place of log odds

per <- function(x, y) x >= 30
plot(p, perim=per)       # suppress output for age < 30 but leave scale alone
#> Error: object 'p' not found

# Take charge of the plot setup by specifying a lattice formula
p <- Predict(fit, age, blood.pressure=c(120,140,160),
             cholesterol=c(180,200,215), sex)
#> Error: object 'fit' not found
plot(p, ~ age | blood.pressure*cholesterol, subset=sex=='male')
#> Error: object 'p' not found
# plot(p, ~ age | cholesterol*blood.pressure, subset=sex=='female')
# plot(p, ~ blood.pressure|cholesterol*round(age,-1), subset=sex=='male')
plot(p)
#> Error: object 'p' not found

# Plot the age effect as an odds ratio
# comparing the age shown on the x-axis to age=30 years

ddist$limits$age[2] <- 30    # make 30 the reference value for age
# Could also do: ddist$limits["Adjust to","age"] <- 30
fit <- update(fit)   # make new reference value take effect
#> Error: object 'fit' not found
p <- Predict(fit, age, ref.zero=TRUE, fun=exp)
#> Error: object 'fit' not found
plot(p, ylab='Age=x:Age=30 Odds Ratio',
     abline=list(list(h=1, lty=2, col=2), list(v=30, lty=2, col=2)))
#> Error: object 'p' not found

# Compute predictions for three predictors, with superpositioning or
# conditioning on sex, combined into one graph

p1 <- Predict(fit, age, sex)
#> Error: object 'fit' not found
p2 <- Predict(fit, cholesterol, sex)
#> Error: object 'fit' not found
p3 <- Predict(fit, blood.pressure, sex)
#> Error: object 'fit' not found
p <- rbind(age=p1, cholesterol=p2, blood.pressure=p3)
#> Error: object 'p1' not found
plot(p, groups='sex', varypred=TRUE, adj.subtitle=FALSE)
#> Error: object 'p' not found
plot(p, cond='sex', varypred=TRUE, adj.subtitle=FALSE)
#> Error: object 'p' not found

if (FALSE) { # \dontrun{
# For males at the median blood pressure and cholesterol, plot 3 types
# of confidence intervals for the probability on one plot, for varying age
ages <- seq(20, 80, length=100)
p1 <- Predict(fit, age=ages, sex='male', fun=plogis)  # standard pointwise
p2 <- Predict(fit, age=ages, sex='male', fun=plogis,
              conf.type='simultaneous')               # simultaneous
p3 <- Predict(fit, age=c(60,65,70), sex='male', fun=plogis,
              conf.type='simultaneous')               # simultaneous 3 pts
# The previous only adjusts for a multiplicity of 3 points instead of 100
f <- update(fit, x=TRUE, y=TRUE)
g <- bootcov(f, B=500, coef.reps=TRUE)
p4 <- Predict(g, age=ages, sex='male', fun=plogis)    # bootstrap percentile
p <- rbind(Pointwise=p1, 'Simultaneous 100 ages'=p2,
           'Simultaneous     3 ages'=p3, 'Bootstrap nonparametric'=p4)
xYplot(Cbind(yhat, lower, upper) ~ age, groups=.set.,
       data=p, type='l', method='bands', label.curve=list(keys='lines'))
} # }

# Plots for a parametric survival model
require(survival)
n <- 1000
set.seed(731)
age <- 50 + 12*rnorm(n)
label(age) <- "Age"
sex <- factor(sample(c('Male','Female'), n,
              rep=TRUE, prob=c(.6, .4)))
cens <- 15*runif(n)
h <- .02*exp(.04*(age-50)+.8*(sex=='Female'))
t <- -log(runif(n))/h
label(t) <- 'Follow-up Time'
e <- ifelse(t<=cens,1,0)
t <- pmin(t, cens)
units(t) <- "Year"
ddist <- datadist(age, sex)
Srv <- Surv(t,e)


# Fit log-normal survival model and plot median survival time vs. age
f <- psm(Srv ~ rcs(age), dist='lognormal')
#> number of knots in rcs defaulting to 5
#> Error in Design(m, formula = formula, specials = c("strata", "cluster")): dataset ddist not found for options(datadist=)
med <- Quantile(f)       # Creates function to compute quantiles
#> Error: object 'f' not found
                         # (median by default)
p <- Predict(f, age, fun=function(x) med(lp=x))
#> Error: object 'f' not found
plot(p, ylab="Median Survival Time")
#> Error: object 'p' not found
# Note: confidence intervals from this method are approximate since
# they don't take into account estimation of scale parameter


# Fit an ols model to log(y) and plot the relationship between x1
# and the predicted mean(y) on the original scale without assuming
# normality of residuals; use the smearing estimator
# See help file for rbind.Predict for a method of showing two
# types of confidence intervals simultaneously.
set.seed(1)
x1 <- runif(300)
x2 <- runif(300)
ddist <- datadist(x1,x2)
y  <- exp(x1+x2-1+rnorm(300))
f <- ols(log(y) ~ pol(x1,2)+x2)
#> Error in Design(X, formula = formula): dataset ddist not found for options(datadist=)
r <- resid(f)
#> Error: object 'f' not found
smean <- function(yhat)smearingEst(yhat, exp, res, statistic='mean')
formals(smean) <- list(yhat=numeric(0), res=r[!is.na(r)])
#> Error: object 'r' not found
#smean$res <- r[!is.na(r)]   # define default res argument to function
plot(Predict(f, x1, fun=smean), ylab='Predicted Mean on y-scale')
#> Error: object 'f' not found

# Make an 'interaction plot', forcing the x-axis variable to be
# plotted at integer values but labeled with category levels
n <- 100
set.seed(1)
gender <- c(rep('male', n), rep('female',n))
m <- sample(c('a','b'), 2*n, TRUE)
d <-  datadist(gender, m); options(datadist='d')
anxiety <- runif(2*n) + .2*(gender=='female') + .4*(gender=='female' & m=='b')
tapply(anxiety, llist(gender,m), mean)
#>         m
#> gender         a       b
#>   female 0.68977 1.11430
#>   male   0.39019 0.48358
f <- ols(anxiety ~ gender*m)
#> Error in Design(X, formula = formula): dataset d not found for options(datadist=)
p <- Predict(f, gender, m)
#> Error: object 'f' not found
plot(p)     # horizontal dot chart; usually preferred for categorical predictors
#> Error: object 'p' not found
Key(.5, .5)

plot(p, ~gender, groups='m', nlines=TRUE)
#> Error: object 'p' not found
plot(p, ~m, groups='gender', nlines=TRUE)
#> Error: object 'p' not found
plot(p, ~gender|m, nlines=TRUE)
#> Error: object 'p' not found

options(datadist=NULL)

if (FALSE) { # \dontrun{
# Example in which separate curves are shown for 4 income values
# For each curve the estimated percentage of voters voting for
# the democratic party is plotted against the percent of voters
# who graduated from college.  Data are county-level percents.

incomes <- seq(22900, 32800, length=4)
# equally spaced to outer quintiles
p <- Predict(f, college, income=incomes, conf.int=FALSE)
plot(p, xlim=c(0,35), ylim=c(30,55))

# Erase end portions of each curve where there are fewer than 10 counties having
# percent of college graduates to the left of the x-coordinate being plotted,
# for the subset of counties having median family income with 1650
# of the target income for the curve

show.pts <- function(college.pts, income.pt) {
  s <- abs(income - income.pt) < 1650  #assumes income known to top frame
  x <- college[s]
  x <- sort(x[!is.na(x)])
  n <- length(x)
  low <- x[10]; high <- x[n-9]
  college.pts >= low & college.pts <= high
}

plot(p, xlim=c(0,35), ylim=c(30,55), perim=show.pts)

# Rename variables for better plotting of a long list of predictors
f <- ...
p <- Predict(f)
re <- c(trt='treatment', diabet='diabetes', sbp='systolic blood pressure')

for(n in names(re)) {
  names(p)[names(p)==n] <- re[n]
  p$.predictor.[p$.predictor.==n] <- re[n]
  }
plot(p)
} # }
